Getting Started

Tunnel Whisperer connects services across separated private networks via resilient HTTPS tunnels. One binary, three roles: the relay admin owns the relay VM, servers join it and expose services, clients import a bundle and connect. This guide walks you through the setup.

Prerequisites

  • Go 1.26+ — to build from source
  • Terraform — for automated cloud relay provisioning (not needed for the manual bring-your-own-VM path)
  • A domain name — pointed at your relay VM (e.g. relay.example.com)
  • A cloud account — Hetzner, DigitalOcean, or AWS (for automated provisioning), or any VM with a public IP

Workflow Overview

                              # role: relay (admin machine)
1. Provision   tw relay create
2. Invite      tw relay invite            (mints a code, waits for the server)

                              # role: server
3. Join        tw join relay.example.com <code>
4. Invite      tw server user invite alice -m 8080:80
               (mints a code, waits for the client)
5. Run         tw server start                 (or tw dashboard / tw service install)

                              # role: client
6. Connect     tw join relay.example.com <code>
               tw client connect

The relay admin provisions the relay and invites servers. Each server operator redeems an invite to join the relay, invites its own users, and runs tw server start. Each client redeems a user invite — which generates their identity locally and never transmits a private key — and runs tw client connect to establish local port forwarding. Every invite is a spoken one-time code confirmed by a short authentication string read back between the two humans involved; see Tenants — security.

The first role command sets the machine's mode

A machine's mode (relay, server, or client) is set by its first role action and is signed for tamper evidence — commands of other roles refuse to run. See Global — the role model.

Pick Your Role

  • Global — the role model, contexts, status, service, proxy, dashboard (everyone)
  • Relay — provision the relay, enroll and manage servers
  • Server — join a relay, manage users, run the tunnel
  • Client — import a bundle and connect
